VPT160
Βασικός Εξοπλισμός
- Flat cylinder head support parallels
- Adjustable support parallels for wedge-shaped cylinder heads
- Fixing crossbeams of Plexiglas plate with plates
- L=380 mm fixing tension rod with nuts and washers
- 500x250x30 mm Plexiglas plate
- 800x250x30 mm Plexiglas plate
- 500x500x8 mm Rubber sheet
- 500x500x3 mm Rubber sheet
- Side-locking plate with quick-release coupling
- Standard equipment instruction manual
Τεχνικά Χαρακτηριστικά
linder head capacity
1350x410x410 mm
Tank capacity
590 l
Maximum cradle travel
600 mm
Heating elements
2 x 4,5 kW
Adjustable work temperature
30 – 90° C
Cradle rotation speed
4 rpm
Cradle up-down speed
60 mm/sec
Hydraulic station motor
0,75 kW
Cradle gearmotor
0,25 kW
Dimensions (LxWxH)
1950x1100x1800 mm
Weight
610 Kg
