Trego VFP-500 is universal, fast and simple to use.
The VFP-500 makes it easy to disassemble and assembling valve springs on cylinder heads on cars, trucks and motorcycles.
VFP500
Περιεχόμενα
- Adjustable table. 45º to the front and 30º to the backside.
- Open pressure foot makes it easy to remove and replace
valve keepers. - Adjustable post 0º-25º
Τεχνικά Χαρακτηριστικά
| Table Dimensions: | Mesurments: |
| Width: 630 mm | Width: 710 mm |
| Depth: 310 mm | Height: 660 mm |
| Press Arm movment: | Depth: 610 mm |
| x=500 mm, z=140 mm * | Weight: 45 kg |
| Air pressure: | Shipping dimensions: |
| 6-10 bar | 800x600x620 mm, 65 kg |
* = Z-movement controlled by a foot operated pedal.
The speed is adjustable in the pedal.
Αξεσουάρ
Pressure foots: 18 mm, 21 mm, 23 mm, 35 mm
Valve Keeper Installer: 4 mm, 5 mm, 6 mm, 7 mm, 8 mm
