Capacity: 40 gallons
Internal measurements: 28” x 20” x 21” in. (excluding auxiliary tank)
Useful measurements: 26” x 16” x 12” in.
Platform measurements: 26” x 16” in.
External measurements: 44” x 29” x 36” in.
Weight: 385 lb.

ELECTRICAL CHARACTERISTICS
• Power Supply: 240V. / 400V.
• Heating element: 3500W. for power supply 240V. and 3750W. optional for 400V.

ULTRASONIC CHARACTERISTICS
• Ultrasonic Power: 1700W. (3400W. p-p).
• 1 ultrasonic generator with 1700W. (1400W. p-p) output power.
• 1 submergible emitter with 1700W. (3400W. p-p) of power built in INOX AISI 316 steel, 1” inch thick. The emitter contains 16 high-performance IBL piezo-electric transducers in titanium-steel.
• Working frequency: 40 KHz sweep system ± 2%.

CONTROL PANEL
• 4.3” inch touch screen. Functional and intuitive access to ultrasound time setting, temperature and peripheric or optional systems. Programmable weekly calendar.
• 6 outputs and 8 inputs temperature module PLC.

FINISHING AND ACCESSORIES
• Tank built in INOX AISI 304 Stainless steel, 0,08” inch thick.
• External panel in fingerprint-resistant steel, 0,03” inch thick.
• Thermo-acustic isolator K-Flex Duct Net, 0,8” inch thick.
• Reinforced pneumatic platform for loading and unloading up to 132 lb.
• 1” inch draining ball valve.
• Height adjustable legs.
• Insulated tank cover in Stainless-Steel with pneumatic
shock absorber.
• Air blow-gun for drying parts.
• Integrated wateflow system. Removes the existing waste on the tank surface, keeping the cleaning equipment in perfect condition.
• (Optional): Filtration system (Stailess-Steel filter with
polypropylene/polyester bag) for waste and mud.

AUTOMOTIVE

•   General workshop
•   Diesel injection workshops
•   Grinding workshops
•   Turbocharger workshops
•   Engine rebuilding work
•   Gearbox repair shops
•   Marine
•   Heavy machinery

INDUSTRIAL

•   Aeronautic industry
